Ceramic beads B205 sand size 0-0.063mm
Ceramic beads B205 sand size 0-0.063mm typically refer to a specific type of zirconium silicate blasting and shot blasting media used in industrial applications, particularly in surface treatment and finishing.
B205 is a fine specification of ceramic sand, the particle size is narrow to get fine and smooth effect.
Characteristics of Ceramic beads B205 sand size 0-0.063mm:
- High strength and wear resistance.
- The ceramic shot has high hardness, with Vickers hardness (microhardness) of 700hv and Rockwell hardness of 600 HRC.
- No dust, high abrasion resistance, and strength make it difficult for a ceramic shot to be broken during sandblasting, so it is not easy to generate dust.
- Sandblasting effect: the surface finish is high.
- It is applicable to various metals and nonmetals, such as titanium alloy, magnesium alloy, aluminum alloy, stainless steel, carbon steel, brass and alloy, acrylic, plastic and other materials.
- It is suitable for dry blasting and wet blasting. The surface of ceramic shot is very smooth, and the wear of sandblasting equipment is very small.
- Ceramic shot has high sandblasting efficiency and long service life, and its recycling times can reach 25 times of glass beads.
- The roundness is high, and the proportion of abnormal balls and snowman balls adhered between the spheres is low.
Chemical composition of Ceramic beads B205 sand size 0-0.063mm:
| Item | Standard Value | Measured Value |
| ZrO2+Y2O3 | 60-70 | 64.88 |
| SiO2 | 28-33 | 25.73 |
| Al2O3 | Max.10 | 7.46 |
| Fe2O3 | Max.0.06 | 0.03 |
| TiO2 | Max.0.20 | 0.14 |
Physical features of Ceramic beads B205 sand size 0-0.063mm:
| Item | Standard Value | Measured Value |
| Particle Size | +0.063mm ＜5% -0.053mm ＜30% | 2.5% 24.5% |
| Specific Gravity | Min. 3.85 g/cm3 | 3.86 g/cm3 |
| Bulk Density | Min. 2.30 g/cm3 | 2.32 g/cm3 |
| Vickers Hardness | Min. 700 HV | 720 HV |
Partical size distribution:
| D10 (um) | D25 (um) | D50 (um) | D75 (um) | D90 (um) |
| 29.48 | 36.77 | 48.12 | 58.52 | 69.90 |
Specification：
| Specification | Particle Range | Diameter | Sieve Retained Ratio |
| B20 | 0.600-0.850 mm | ＞0.85mm | ＜5% |
| 0.6-0.85 mm | ＞90% | ||
| ＜0.6 mm | ＜5% | ||
| B30 | 0.425-0.600 mm | ＞0.6 mm | ＜5% |
| 0.425-0.60 mm | ＞90% | ||
| ＜0.425 mm | ＜5% | ||
| B40 | 0.250-0.425 mm | 0.425-0.500 mm | ＜5% |
| 0.250-0.425 mm | ＞90% | ||
| ＜0.250 mm | ＜5% | ||
| B60 | 0.125-0.250 mm | 0.250-0.300 mm | ＜5% |
| 0.125-0.250 mm | ＞90% | ||
| ＜0.125 mm | ＜5% | ||
| CB60 | 0.125-0.250 mm | 0.250-0.300 mm | ＜5% |
| 0.180-0.250 mm | 40-55% | ||
| 0.125-0.180 mm | 35-55% | ||
| 0.106-0.125 mm | ＜8% | ||
| ＜0.106 mm | ＜5% | ||
| CB60+ | 0.125-0.250 mm | 0.250-0.300 mm | ＜5% |
| 0.180-0.250 mm | 65-75% | ||
| 0.125-0.180 mm | 25-35% | ||
| 0.106-0.125 mm | ＜5% | ||
| ＜0.106 mm | ＜2% | ||
| B80 | 0.180-0.250 mm | 0.250-0.300 mm | ＜10% |
| 0.180-0.250 mm | 85-100% | ||
| 0.125-0.180 mm | ＜10% | ||
| B100 | 0.125-0.180 mm | ＞0.180 mm | ＜10% |
| 0.125-0.180 mm | ＞80% | ||
| ＜0.125 mm | ＜10% | ||
| B120 | 0.063-0.150 mm | 0.150-0.212 mm | ＜3% |
| 0.125-0.150 mm | 35-45% | ||
| 0.063-0.125 mm | 55-65% | ||
| ＜0.063mm | ＜5% | ||
| NB120 | 0.063-0.125 mm | ＞0.212 mm | ＜3% |
| 0.125-0.212 mm | ＜10% | ||
| 0.063-0.125 mm | ＞80% | ||
| ＜0.063 mm | ＜10% | ||
| FB120 | 0.125-0.150 mm | ＞0.150 mm | ＜5% |
| 0.125-0.150 mm | ＞90% | ||
| ＜0.090 mm | ＜5% | ||
| B125 | 0-0.125 mm | ＞0.125 mm | ＜5% |
| B150 | 0.063-0.150 mm | ＞0.150 mm | ＜5% |
| ＜0.063 mm | ＜5% | ||
| B170 | 0.045-0.150 mm | ＞0.150 mm | ＜5% |
| 0.045-0.150 mm | ＞90% | ||
| ＜0.0.045 mm | ＜5% | ||
| B170+ | 0.090-0.106 mm | ＞0.106 mm | ＜5% |
| 0.090-0.106 mm | 40-65% | ||
| 0.063-0.090 mm | 20-50% | ||
| ＜0.063 mm | ＜10% | ||
| BZ170 | 0.045-0.090 mm | ＞0.090 mm | ＜5% |
| 0.063-0.090 mm | 70-85% | ||
| 0.045-0.063 mm | 10-30% | ||
| ＜0.045 mm | ＜7% | ||
| BY170 | 0.045-0.090 mm | ＞0.090 mm | ＜5% |
| 0.045-0.090 mm | ＞85% | ||
| ＜0.045 mm | ＜10% | ||
| WB170 | 0-0.090 mm | ＞0.090 mm | ＜5% |
| B205 | 0-0.063 mm | ＞0.063 mm | ＜5% |
| B400 | 0.030-0.063 mm | ＞0.063 mm | ＜5% |
| ＜0.053 mm | ＜30% | ||
| B505 | 0.010-0.030 mm | ＞0.053 mm | ＜5% |
*Other customized sizes are available.
Applications of Ceramic beads B205 sand size 0-0.063mm:
- Medical treatment. It works for surface treatment such as deburring of stainless steel surgical instruments and titanium alloy human implanted devices.
- High iron field: it can be used for sandblasting the surface of high iron aluminum alloy parts to improve the metal texture and form a smooth satin effect. Used for grinding and finishing of high-speed rail.
- Automotive field: ceramic shot can be used for surface cleaning and deburring of Automotive Engine Castings; It is used to clean the welds and welding spots on the car floor and prepare for subsequent spraying; Used for shot peening of automobile springs to improve fatigue life. It is used for beautification and sandblasting of aluminum alloy automobile wheels to eliminate stress and improve impact resistance.
- Mold and machining: used for sandblasting of stainless steel mold, copper mold and aluminum alloy mold, such as tire mold, injection mold and stamping mold, to improve surface finish. Clean the flash and burr of machined parts.
- Electronic equipment field: the ceramic shot is used for sandblasting the shells of mobile phones, tablet computers and watches made of aluminum alloy or stainless steel. It can adjust the roughness and gloss of the surface as required, and has the characteristics of anti-fingerprint.
- Kitchen utensils industry: it is used for sandblasting of high-quality stainless steel cookware, pot bottom, soup spoon and other products, giving the products delicate metal texture and certain antibacterial ability.
- Glass products industry: used for atomization treatment of glass, replacing hydrofluoric acid chemical etching process to prevent pollution.
- Shot peening of aviation parts: used to improve the fatigue resistance of carbon steel, titanium alloy, aluminum alloy and other aviation mechanical parts and eliminate surface stress. Moreover, it can be used for surface strengthening of aircraft wings, aeroengine turbine blades, turbine discs, gears and landing gear.
Ceramic microbeads B205 for surface treatment Package:
